Product Introduction

Ketian PVC Coated Overlay is a specialized material for smart cards, featuring high adhesive strength and excellent physical stability. It enhances the surface protection and adhesion of cards: through the hot-pressing process, it provides scratch-resistant and stain-resistant functions to the card surface, ensures firm bonding of all card layers, and offers wear-resistant protection. Additionally, it complies with RoHS and REACH environmental standards.

Moreover, as a professional manufacturer of smart card base materials, our PVC Coated Overlay possesses excellent lamination compatibility and outstanding dimensional stability, making it a reliable choice for smart card producers worldwide.

Product Features

1. High Adhesive Strength: Exhibits strong adhesion to PVC card substrates/inlay. The 90° peel strength of the magnetic card ink printing layer is ≥6N/cm, ensuring firm bonding without delamination.

2. Strong Physical Stability: Boasts excellent resistance to damp-heat aging, high tensile strength, and good post-forming dimensional stability.

3. Superior Protective Performance: Prevents printed patterns from being scratched after lamination, extending the service life of the card.

4. Flexible Processing Adaptability: The thickness can be selected within the range of 0.04mm～0.15mm, and specifications can be customized according to customer requirements. It is compatible with various card-making processes such as lamination at 120℃-150℃, featuring strong compatibility.

5. Environmental Compliance: Uses water-based environmentally friendly adhesive; no solvent volatilization or waste gas emission during the card-making process, complying with international environmental standards such as RoHS and REACH.

Technical Parameters

Item	Specification
Thickness	0.04mm～0.15mm
Color	Transparent
Vicat Softening Point(B50)	72℃～78℃
Peel Strength	≥6N/cm
Tensile Strength	Machine Direction (MD) ≥12.0MPa , Transverse Direction (TD) ≥12.0MPa
Delivery Form	Sheet/Roll
Type	Non-adhesive Film / Adhesive-coated Film / High-strength Adhesive-coated Film / Laser Adhesive-coated Film
Certification	Compliant with RoHS, REACH, GRS

Application Fields

Our PVC Coated Overlay is mainly used in the production of various plastic cards, including:

1. Non-contact Smart Cards: Subway cards, public transport cards, access control cards

2. Financial Payment Cards: Credit cards, debit cards, gift cards

3. Commercial Membership Cards: Membership cards for various supermarkets, shopping malls, and service industries

Product Storage

1. The product should be stored in a cool and dry indoor area, stacked horizontally. Please avoid direct sunlight and heavy pressure, and keep the original packaging sealed to prevent moisture. Storage temperature: room temperature.

2. Under normal storage conditions, the shelf life is one year (subject to the manufacturer's instructions).

3. When in use, follow the principle of taking only what is needed for use. Any remaining product should be sealed and stored promptly, and the opened product should be used up as soon as possible.

An Ideal Choice for Customized Smart Card Solutions

Ketian has professional expertise and an annual production capacity of 15,000 tons, enabling it to fulfill large-volume, high-quality customized orders for PVC smart card base materials. We are ready to offer tailor-made solutions to meet your specific technical and design requirements. Contact us now via email: info@ketian.net.cn, to request free samples and obtain a detailed quote for your project.
